EVIRT Italia unveils the revolutionary Spline Tech rolling machine series

EVIRT Italia is proud to introduce its brand-new Spline Tech series of rolling machines, specifically designed for rolling splined and toothed profiles with maximum precision and productivity.

What is spline rolling?

Spline rolling is a forming process used to create splined and toothed profiles on shafts and cylindrical components. These profiles are widely employed in applications involving torque transmission and rotary movements, such as half-shafts, drive shafts, compression shafts, braking systems, components for electric and off-road vehicles and more.

In recent years, with the growing search for alternative fuel sources, EVIRT Italia has made significant investments aimed at improving the efficiency of toothed components for torque transmission. The goal is to ensure a more precise and rigid coupling compared to traditional knurling, providing more efficient and reliable power transmission.

Flat rolling vs. cylindrical rolling

Flat dies rolling, a traditional method that employs two opposing horizontal rack tools, faces some limitations in terms of precision and profile quality. While widely used, this approach can struggle with meeting tight tolerances and very fine surface finishes.

EVIRT Italia's Spline Tech series revolutionizes spline rolling with an innovative method that uses two directly driven and absolutely rigid cylindrical dies rollers. This cutting-edge system overcomes the limitations of flat dies rolling, offering several advantages: the resulting profiles have superior quality and extremely precise tolerances, at the same time ensuring perfect fittings and frictionless operation.

Spline Tech series by EVIRT Italia: efficiency and innovation

The Spline Tech series developed by EVIRT Italia enhances the benefits of Smart rolling through an innovative system that rigidly couples spindles and brushless motors, ensuring the workpiece is always at the center of the working area. This guarantees perfect symmetry of cylinder movements, resulting in a significantly higher quality final product.

The Spline Tech series is compatible with any automation system and allows up to 5 different tool sets with various splines and/or teeth to be managed on the same shaft. The process can be continuously monitored via CNC control and the integrated EVIRT comfort-HMI calculation system, enabling real-time analysis of rolling numbers and force, increasing traceability, and reducing setup change times.

In addition to standard rolling, EVIRT Italia's Spline Tech series also offers two advanced operating modes that further expand its capabilities: incremental rolling (single-pass), ideal for machining complex profiles in a single cycle; and "through-feed" rolling, designed for rolling profiles on hollow shafts, allowing the processing of profiles longer than the tool thickness through axial movement of the workpiece.

For more information about the Spline Tech series and its full range of products, we invite you to visit EVIRT Italia's online stand and contact the company using the provided references.
